APW121417b_14V-17V EMC
Note:
You can check the exact version at the product tag which is on the side of the power supply and find the newest firmware accordingly from official website.
There are many versions of this power supply, it is recommended to consult customer service before purchasing>>Contact now
| APW12 | ||
| OUT1 | DC Voltage | 14V-17V |
| Rated Current(220 V input) | 182A (maximum 212A) | |
| Ripple & Noise | <1% | |
| Source adjustment rate | <1% | |
| Load Regulation | <1% | |
| Start-up and rise time | <2S | |
| Power-off retention time | >10mS | |
| OUT2 | DC Voltage | 12.3V |
| Rated Current(220 V input) | 18A | |
| Ripple & Noise | <1% | |
| Voltage Accuracy | 12.2V—12.4V | |
| Source adjustment rate | <1% | |
| Load Regulation | <1% | |
| Start-up and rise time | <2S | |
| Power-off retention time | >10mS | |
| Input | Voltage Range | 200-240V AC |
| Frequency Range | 47-63Hz | |
| Power Factor | >0.99(full load) | |
| Leakage Current | <1.5mA（220V 50Hz） | |
| Protection | Input undervoltage protection value | 80-89V AC |
| Output Short Circuit | Yes | |
| Over-temperature protection | Yes | |
| Output overcurrent protection value | 260A-340A | |
| （protection value varies under different voltage） | ||
| Environment | Operating Temperature | -20-45℃ |
| Operating Humidity | 20%-90%RH（non-condensing） | |
| Altitude | < 2000m | |
| Structure | Dimensions | 254.6mm*251.6mm*63mm |
| Net Weight | 3.6KG | |
| Cooling method | Forced air cooling | |
| Noise | 45dBA | |
Purchasing Guidelines
NOTES
1. One account can purchase a maximum of 200 units.
2. The shipping costs, cutsoms charges, and taxes(if any) are not included in the retail price shown above.
3. After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by BITMAIN.
4. The pictures shown are for reference only; the final shipment version shall prevail.
SHIPPING DETAILS
1. The products are made in China. If shipping to the U.S., customers will need to pay tariff.
2. Shipments will be scheduled on a first-paid-first-ship basis for orders on which BITMAIN has received full payment.
3. You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It’s highly recommended to be aware of local customs clearance policies and to prepare all customs documentation ahead of time to avoid any customs clearance delays or unexpected costs.
